The data displayed below were collected during a joint project between the following departments at Montana Tech of The University of Montana: Geophysical Engineering and the Montana Bureau of Mines and Geology. The samples represent sandstones collected and analyzed for their potential use as proppant material.
Sample Name | GFS-10-SV-13 | Site Name | GFS-10-SV-13 |
---|---|---|---|
Latitude | 47.46126 | Longitude | -111.21637 |
Geomethod | NAV-GPS | Datum | NAD83 |
Elevation | 3384 | Township | 20N |
County | CASCADE | Range | 04E |
100K Quad | GREAT FALLS SOUTH | Section | 27 |
24K Quad | SOUTHWEST GREAT FALLS | Quarter Section | BB |
Sample Taken | YES | ||
Sample Date | 8/31/2013 | Formation Name | Kootenai Formation, Sunburst Member (Kks) |
Sampler Name | SUSAN VUKE | Sampler Notes | AT LG BOULDER FROM OC ABOVE, ALONG FENCE LINE GIBSON FLATS RD; QUARTZOSE, ROCK COLOR CHART; WHITE (N9), VERY LIGHT GREEN (N8) & VERY PALE ORANGE (10 YR 8/2); POROUS; FINE GRAINED; NO REACTION TO ACID |
Thickness | 40-60 FT | Extent | OVER 1 MILE AROUND HILL |
References | |||
Sphericity | 0.64 |
---|---|
Roundness | 0.55 |
First Primary | 70 |
Second Primary | 140 |
Available Documents View document [GFS_10_SV_14_PRECRUSH2092015_8_3_14_14_1.pdf]View document [GFS_10_SV_14_SPHERE_ROUND2102015_8_3_14_14_6.pdf] View document [GFS_10_SV_14_CRUSH7K0502015_8_3_14_14_22.pdf] |
