The data displayed below were collected during a joint project between the following departments at Montana Tech of The University of Montana: Geophysical Engineering and the Montana Bureau of Mines and Geology. The samples represent sandstones collected and analyzed for their potential use as proppant material.

General Information
Sample Name CFD-13-SV-14 Site Name CFD-SV-14
Latitude 46.72089 Longitude -111.280821
Geomethod NAV-GPS Datum WGS84
Elevation 5032 Township 12N
County MEAGHER Range 04E
100K Quad CANYON FERRY DAM Section 7
24K Quad WATSON Quarter Section CD
Sample Taken YES
Sample Date 9/26/2014 Formation Name Flathead Formation (_f)
Sampler Name SUSAN VUKE Sampler Notes ALONG LINGSHIRE RD
Thickness INDETERMINATE Extent LARGE BLOCKS OF SS, NO OC APPARENT
References

Site Photographs
Sample Characteristics
Meets API Minimum Standards Minerology
NO QUARTZ
Pre Wash Weight (g) Post Wash Weight (g)
875.5
Material Notes
USED CONE CRUSHER

Sieving Results

Reported Sample Weight (g): 110
Mesh Empty (g) After (g) Mass of Sample (g) Percent of Total Photo
16 334.4 337.9 3.5 3.18 %
20 306 311.5 5.5 5.00 %
30 296.1 308.6 12.5 11.36 %
40 285.6 307.6 22 20.00 %
50 263.9 289 25.1 22.82 %
60 260.3 272.2 11.9 10.82 %
70 284 291.8 7.8 7.09 %
140 253 270.8 17.8 16.18 %
pan 355.3 359.2 3.9 3.55 % No photo available
Totals 110.00 100.00 %
Error (Init/Final Mass) 0.00 %
Lab Results
Sphericity 0.63
Roundness 0.55
First Primary 30
Second Primary 50

Available Documents

    View document [CFD_13_SV_14_PRECRUSH0522016_2_5_12_35_3.pdf]
    View document [CFD_13_SV_14_SPHER_ROUND_500492016_2_5_12_35_10.pdf]
