The data displayed below were collected during a joint project between the following departments at Montana Tech of The University of Montana: Geophysical Engineering and the Montana Bureau of Mines and Geology. The samples represent sandstones collected and analyzed for their potential use as proppant material.
Sample Name | LIMA-09-SV-14 | Site Name | LIMA-SV-14 |
---|---|---|---|
Latitude | 44.574922 | Longitude | -112.678518 |
Geomethod | NAV-GPS | Datum | WGS84 |
Elevation | 6738 | Township | 14S |
County | BEAVERHEAD | Range | 09W |
100K Quad | LIMA | Section | 34 |
24K Quad | GALLAGHER GULCH | Quarter Section | AB |
Sample Taken | YES | ||
Sample Date | 8/13/2014 | Formation Name | Quadrant Formation (*q) |
Sampler Name | SUSAN VUKE | Sampler Notes | TENDOY RANGE: ALONG EAST CREEK CAMPGROUND ROAD OFF OF EAST FORK LITTLE SHEEP CREEK |
Thickness | ~50 FT | Extent | SAMPLED ALONG RD (PHOTO A), BUT BETTER EXPOSURES ACROSS CREEK ON OTHER SIDE (PHOTO B) |
References | |||
Sphericity | 0.67 |
---|---|
Roundness | 0.49 |
First Primary | 70 |
Second Primary | 140 |
Available Documents View document [LIMA_9_SV_14_PRECRUSH0472015_8_13_10_33_43.pdf]View document [LIMA_09_SV_14_SPHER_ROUND_1400422015_8_13_10_35_10.pdf] |
